The reader is designed by ITLONG company based on the non-contact R/W technology. It applies special hardware circuit design, multi-protection inside to protect data security. Non-contact IC card is in line with international standard. Reader and reader use logic encryption algorithm during reading and writing, to prevent from being deciphered. Each card has a unique code and can not be copied.
Standalone Access Control Reader:
TECHNICAL PARAMETERS:
Power: DC 12V±10% , 2A
Working Environment: temperature:－10~+60℃
Relative Humidity: ≤95% no condensation
Card Type: CPU, IC card
; Read Distance: 30~50mm
Respond Time: ≤0.3S
Communication Interface: RS485
Transmission Distance:1.2km
Dimension: 120×100×21.34mm
TECHNICAL PARAMETERS:
Power: DC 12V±10% , 2A
Working Environment: temperature:－10~+60℃
Relative Humidity: ≤95% no condensation
; Card Type: CPU, IC card
Read Distance: 30~50mm
; Respond Time: ≤0.3S
Communication Interface: RS485
Transmission Distance:1.2km
Dimension: 120×;100×21.34mm
; TECHNICAL PARAMETERS:
Working Frequency: 13.56MHz
Power Supply: DC 24V
Data Transmission Standard:13.56MHz: ISO14443A
Reading Range: ≤5CM
Read/Write Function: Read/Write
Power Consumption: < 2W
Communication Interface: RS485
Data Transfer Rate: 9600（N，8，1）
Working Temperature: -10℃— 60℃
; Button Material: Capacitive touch keyboard
; Protection Standard: IP54
Shell Material：ABS+PC
Color: Sliver
Dimension(L×D×H):120*100*21mm
TECHNICAL PARAMETERS:
; Working Frequency: 13.56MHz
Power Supply: DC 24V
; Data Transmission Standard:13.56MHz: ISO14443A
Reading Range: ≤5CM
; Read/Write Function: Read/Write
Power Consumption: < 2W
Communication Interface: RS485
Data Transfer Rate: 9600（N，8，1）
Working Temperature: -10℃— 60℃
Protection Standard: IP54
; Shell Material：ABS+PC
Color: Sliver
Dimension(L×D×H):120*100*21mm
